機械特點 MACHINE FEATURES: ●Ten-shaped direction towards the main axis The cross-shaped approach to the back main shaft design enables the main shaft and the back shaft to be processed simultaneously or separately, thereby saving processing time and providing high and diverse front-back mixed processing capabilities. ● Excess materials shortage By choosing the coarse material sleeve, it can be used as a router instead of a cutting machine. The leftover material is approximately 50mm in length, which can effectively reduce the material cost. ●Raw material processing Choose the roughing sleeve. Non-ground rod materials can also be processed on the centering machine. The material tolerance can be tolerated at 0.1mm.
| ●Cross Travel Sub-spindle Cross travel sub spindle design.The main and sub spindles can work either one at a time or simultane- ously for reduced machining duration.This design brings multi-function front and rear machining. ●Short Remnant Material ●Raw Material Machining 0.1mm material tolerance can be achieved by using the Rough Material Bushing. 選配( option ): ●Five outer-diameter tool holders 2 pieces + 3 pieces (replaceable type) side drilling cutter tool holder 5 sets of internal diameter cutting tool holders on the front side 5 sets of internal diameter knife holders on the back of the knives ●5 pcs O.D.Turning Tool Holder +I p ( l l) l rWorking Driven Tool Holde ●5 pcs Back I.D.Stationary Tool Holder Spindle / Back spindle equipped with built-in motor, standard with C-axis Positioning, with the option to be equipped with a high-resolution CS axis The main/sub-spindle are equipped with built-in motor,standard with C axis orientation, |
刀具系統圖 TOOL POST: 4 pcs cross working driven tool holder 4 支側面鑽銑刀具刀座 4 pcs I.D.stationary tool holder 4 支正面内径刀具刀座 | 3 pcs front working driven tool holder(opt.) 3支正面鑽銑刀具刀座(選配) 4 pcs back I.D. stationary tool holder 4支背面固定刀具刀座 | 4 pcs back I.D.stationary tool holder 4支背面固定刀具刀座 6 pcs O.D.turning tool holder 6支外徑刀具刀座 |
