Mini-88 CNC Lathe

下載PDF檔案加入詢價車
    Servo turrets can greatly boost machining efficiency

    Chip conveyors make chip removal much easier

    The centralized finished product unit features a compact design that saves space

    The comb-type tool post enables faster tool changes and can hold up to 7 cutting tools. When paired with a servo turret, it significantly improves machining efficiency

    The spindle can be fitted with either a collet chuck or a three-jaw chuck as preferred
特点介紹

2025polygim_extrap_438910_140215_2908654.png'

Processing Examples


Designs to Save Labor and Costs -

Automatic Loading and Unloading Device




标准配件
    25-type Collet Chuck - MINI-88
    20-type Collet Chuck - MINI-88-20
    Chuck Foot Switch (1 piece) - MINI-88
    Work Light (1 piece)
    Tools & Tool Box (1 set)
    Coolant System (1 set)
    Machine Leveling Blocks (4 pieces)
    Upper Tool Post - MINI-88 (2 pieces) | MINI-88-20 (1 piece)
    Lower Tool Post - MINI-88 (2 pieces) | MINI-88-20 (1 piece)
    Internal Boring Tool Holder - MINI-88 (4 pieces) | MINI-88-20 (1 set)
    Single Boring Sleeve (2 pieces each) - MINI-88 (6/8/10/12/16 mm) | MINI-88-20 (6/8/10/12 mm)
选择配件
    Servo Octagonal Turret (1 piece) (Only applicable to MINI-88)
    3-Jaw Chuck (1 piece) (Only applicable to MINI-88)
    Finished Product Collecting Unit (1 set)
    Chip Conveyor (1 unit)
    Chip Bin (1 unit)
产品规格
ProjectMINI-88MINI-88-20
Maximum Machining Outer Diameter60 mm (配三爪) / 26 mm (配筒夾)21 mm
Maximum processing length棒材外徑 x 3棒材外徑 x 3
Rotating diameter on the slide base120 mm120 mm
X-axis (vertical) travel stroke170 mm170 mm
Z-axis (horizontal) travel170 mm170 mm
Spindle through-hole diameter34 mm23 mm
Bar accommodating diameter26 mm21 mm
Spindle noseØ85 mm-
Spindle Chuck4"-
Spindle Motor2.2 kW / 3 H.P.2.2 kW / 3 H.P.
Spindle Speed100-5000 r.p.m.100-8000 r.p.m.
Rapid movement of X and Z axes15 m/min15 m/min
Minimum input unit0.001 mm0.001 mm
Use cutting tools16 mm16 mm
Use cutting toolsØ20 mmØ16 mm
Cooling auxiliary motor1/4 H.P.1/4 H.P.
Machine Dimensions1200 x 1000 x 1500 mm1100 x 1000 x 1500 mm
Machine Net Weight1058 kgs1008 kgs
* 我们保留更改设计的权利，恕不另行通知。
